DMD 4070

  • As required in IEC/EN 61000-4-6
  • Suitable for BCI testing per ISO 11452-4, RTCA/DO-160 section 20, MIL-STD-461 CS114 and various automotive standards
  • Active/passive operation for wide dynamic range
  • Suitable for common mode and differential mode measurements
  • Suitable for NSG 4070
  • Ruggedly designed

  • Overview +


    The monitoring device DMD 4070A can be used as an active or passive current sensor probe to measure the current in a conductor without connecting it directly. The DMD 4070A allows fast and easy measurement as it can be quickly clamped around the current carrying conductor. The DMD 4070A is characterized over the frequency range from 4 kHz to 400 MHz. It can be used for the procedure for clamp injection when the common-mode impedance requirements cannot be met given in chapter 7.4 of IEC / EN 61000-4-6. The DMD 4070 can also be used for differential impedance requirements with current up to 50 A as current monitor for BCI testing as per ISO 11452-4, RTCA / DO-160 section 20, MIL-STD-461 CS114 (including version “G“) and various automotive standards.
