Transient immunity standards like LV 124 and ISO 16750 define immunity tests for real-world problems occur on battery systems including supply voltage dips, dropouts, and various types of ripple.
Defined in ISO 16750-2 and LV 124, and many other OEM standards, ripple can be either sine wave noise coupled often with transformers, or fast square waves on to battery voltage.
Some standards are written so that a fast semiconductor switch must be used to achieve the fast rise and fall times, or define very low, or very high-impedance open circuit simulations not possible with battery simulators directly.
Besides various voltage ramps and ripple testing, these standards require very specific type of dropout switch on signal/data and power lines.
Most battery simulators do very little on their own and require a control signal to drive them. Our powerful EMC-specific arbitrary waveform generators are designed specifically for automotive applications.
Accessories for automotive supply voltage variation testing.
