Defined in ISO 16750-2 and LV 124, and many other OEM standards, ripple can be either sine wave noise coupled often with transformers, or fast square waves on to battery voltage.
Transormer for ripple according to Ford FMC 1278 and SAE J1113-2 and ISO 11452-10. Secondary 50A, 600V isolation.
CN 200N1 transormer for ripple according to Ford FMC 1278 and SAE J1113-2 and ISO 11452-10. Secondary 50A, 600V isolation.
SNG 200P - EHV-16 Fast Edge Switching Noise The SNG 200P is designed to simulate high voltage events in electrical vehicles according to EHV-16.
Transformer for HV applications like electric vehicles. 1200V isolation.
Low-frequency signal / amplifier for ripple testing and magnetic field testing
High power ripple generator to perform ripple immunity test on high voltage electric vehicle components (HV batteries, motor inverters, DC-DC converters etc.).
