Programmable AC/DC Power Sources

Ametek CTS offers a wide range of power sources which specifically target EMC, MIL/Avionics and electrical vehicle testing. Several series are available that range from basic 50/60Hz source for harmonics and flicker testing up to high performance AC and DC sources.

Single Phase

Single phase power sources are available from 3kVA up to 7 kVA. The EM Test ACS 500N series offers basic performance targeted for 50/60 Hz harmonics and flicker testing. The Teseq NSG 1007 series is the mid range solution for harmonics and flicker as well as immunity testing according IEC 61000-4-13 and other IEC standards. The EM Test NetWave series is our flagship and offers unmatched performance: 5kHz bandwidth and 8V/us slew rate for perfoming demanding tests on military, avionics and electrical vehicle devices.
Keep Reading
Three Phase

Three phase power sources are available from 10kVA up to 108 kVA in single units and 270kVA for multi-unit conifgurations. The EM Test ACS 503N series offers basic performance targeted for 50/60 Hz harmonics and flicker testing. The Teseq NSG 1007 series is the mid range solution for harmonics and flicker as well as immunity testing according IEC 61000-4-13 and other IEC standards. The EM Test NetWave series is our flagship and offers unmatched performance: 5kHz bandwidth and 8V/us slew rate for perfoming demanding tests on military, avionics and electrical vehicle devices. Available from 20 kVA up to 270 kVA multi-unit configurations, delivering up to 690 VAC and 1120VDC.
Keep Reading
Options & Accessories

Expand your testing range by adding accessories and options to your electronic power sources.
Keep Reading
