RF CDN-Emission Testing

CISPR 15 edition 9 presents a variety of approaches to measure the radio disturbance characteristics of electrical lighting equipment. Among these methods, is the CDNE (Coupling/Decoupling Network for Emission measurement). This method provides guidelines for utilizing a coupling/decoupling network (CDNE) to accurately measure disturbance voltages within the frequency range of 30 to 300 MHz.

CDNE Series

A wide range of CDNE (Coupling/Decoupling Network for Emission) solutions tailored specifically for emission testing in accordance with CISPR 15 standards. A suitable CDNE can be selected based on the number of lines and intended application.
Keep Reading
Accessories

AMETEK CTS offer a comprehensive accessory kit that includes all the necessary adapters to perform function tests, verification measurements, and calibration for the CDNE series.
Keep Reading
