Product Groups

  • Automotive Electrical Disturbances

    These automotive electrical disturbances occur regularly in the vehicle primarily due to switching of various vehicle components and affected by the vehicle harness and other parallel loads. There are both emissions and immunity tests required by the standards, of which there are many. The main standards like ISO 7637-2 and ISO 16750-2 define both how these pulses must be simulated and how they are measured and with what limits. The vehicle manufacturers, who are ultimately responsible, often take these requirements and expand or modify them.

    Keep Reading
  • Automotive Supply Voltage Variations

    Transient immunity standards like LV 124 and ISO 16750 define immunity tests for real-world problems occur on battery systems including supply voltage dips, dropouts, and various types of ripple.

    Keep Reading
  • Automotive Battery Simulators

    Battery simulators replace the vehicle battery in the test environment. These sources must fulfill various criteria concerning power rating, voltage, fast slew rate, very low impedance, low noise, etc. depending on the particular application. Pulse 2b, pulse 4, sine wave noise and other complex simulations are all supported. Our one, two and four-quadrant amplifiers are perfectly suited for ISO 7637 compliant simulated conducted transient testing. Offering EMC-focused combinations of features that exist in no other battery simulator, EM TEST and Teseq brand battery simulators are the right solution for your EMC needs.

    Keep Reading
  • Electrostatic Discharge ESD

    Electrostatic Discharge (ESD) tests are used to verify complete systems and duplicate disturbances in installations. Our ESD simulators fulfill the requirements of all major ESD standards. Thanks to stabilized and monitored HV output all Teseq and EM TEST simulators exceed this need by far and guarantee optimized reproducibility of tests. All models are type-approved and calibrated to IEC/EN 61000-4-2. A comprehensive range of over 100 additional network modules are available for testing to various standards including ISO 10605.

    Keep Reading
  • Harmonics & Flicker

    Ametek CTS offers complete harmonics and flicker measurement test systems which compiles with the latest IEC/EN standards, including IEC 61000-3-2 and IEC 61000-3-3. The programmable power generation capability of up to 108 kVA provides more than ample power to cater for a wide range of Equipment Under Test (EUT). In addition to harmonics and flicker testing capability, the AC/DC power source used in the system is capable of testing to a wide range of power quality immunity tests including IEC 61000-4-13.

    Keep Reading
  • Programmable AC/DC Power Sources

    Ametek CTS offers a wide range of power sources which specifically target EMC, MIL/Avionics and electrical vehicle testing. Several series are available that range from basic 50/60Hz source for harmonics and flicker testing up to high performance AC and DC sources.

    Keep Reading
  • Dips, Interrupts & Variations

    Ametek CTS offers high end single and multifunctional solutions for simulating Dips, Interrupts and Variations according to IEC/EN 61000-4-11 and IEC/EN 61000-4-29 standards. The EM TEST compact NX series and Teseq NSG 3000A series offers single phase standalone Dips, Interrupts & Variation testing as well as combined with burst, surge, telecom and ringwave. The EM Test PFS 503N products and the Teseq Profline with Option 11 offer three phase Dips, Interrupts & Variation testing.

    Keep Reading
  • Ring Wave / Damped Oscillatory

    Ametek CTS offers high end combined or single function solutions for simulating Ring Wave pulses for immunity testing. This conforms with international, national and manufacturers' standards including IEC/EN 61000-4-12 and ANSI C62.41 & 45.

    Keep Reading
  • Transient Generators (Surge, Burst)

    Ametek CTS offers high end combined or single function solutions for simulating Surge and Burst pulses for immunity testing which comply with international, national and manufacturers' standards including IEC/EN 61000-4-4, IEC/EN 61000-4-5, ANSI C62.41 & 45, ANSI TIA 968-B. and ITU-T.K series. Pulses include the classic Combination Wave Surge (1,2/50 & 8/20), Telecom Surge (10/700 & 5/320) as well as Burst. With the EM Test compact NX series and Teseq's NSG 3000A series a wide range of products is available to perfectly match your need.

    Keep Reading
  • Magnetic Fields

    AMETEK CTS offers systems for testing immunity to low frequency, pulse and DC magnetic fields.

    Keep Reading
  • Amplifiers - Solid State

    From standard products to one-off specials, through our three brands of Milmega, IFI and Teseq, Ametek CTS offers a wide range of Solid State and Solid State Pulsed amplifier products to meet application requirements including EMC, Military, Communications, Instrumentation and High Energy Physics. Functioning as either standalone instruments via an intuitive user interface or integrated as part of Turnkey RF Test System, these robust dependable modular amplifiers offer outstanding cost of ownership that meets today's and tomorrow's needs through upgradability.

    Keep Reading
  • Amplifiers - Solid State Pulsed

    From standard products to one-off specials, through our three brands of Milmega, IFI and Teseq, Ametek CTS offers a wide range of Solid State and Solid State Pulsed amplifier products to meet application requirements including EMC, Military, Communications, Instrumentation and High Energy Physics. Functioning as either standalone instruments via an intuitive user interface or integrated as part of Turnkey RF Test System, these robust dependable modular amplifiers offer outstanding cost of ownership that meets today's and tomorrow's needs through upgradability.

    Keep Reading
  • Amplifiers - CW TWT

    Covering the frequency range of 2 to 18 GHz IFI designed CW or GT- TWTA ( continuous Wave or gridded pulse traveling wave tube amplifier) offer a wide range of dependable products. Whether you require wideband or ultra-wideband, IFI has the right TWTA amplifier combinations to fulfil all your testing requirements, from EMC and instrumentation applications to EW and ECM jamming for commercial and military markets.

    Keep Reading
  • Amplifiers - Pulsed TWT

    Covering the frequency range of 2 to 18 GHz IFI designed Pulsed - TWTA (Traveling wave tube amplifier) offer a wide range of dependable products. Whether you require wideband or ultra-wideband, IFI has the right TWTA amplifier combinations to fulfil all your testing requirements, from EMC and instrumentation applications to EW and ECM jamming for commercial and military markets.

    Keep Reading
  • Amplifiers - Millimeter TWT

    Covering the frequency range of 18 to 40 GHz IFI's dependable line of Millimeter RF amplifiers offers multiple power and bandwidth combinations. These millimeter TWT amplifiers give you the right frequency increments and power output levels that you need for today’s stringent test applications. Our millimeter TWTA (traveling wave tube amplifiers) are available for both commercial and military applications.

    Keep Reading
  • RF Immunity Test Systems

    Signal generators covering a broad frequency range till 6 GHz, including broadband noise generator. These generators include options of full front panel control, EUT monitoring as well as remote control. AMETEK CTS also offer different software options for remote control testing.

    Keep Reading
  • RF Coupling Networks/ LISN

    Coupling decoupling networks (CDN), CN, CDND, CDNE and line impedance stabilization networks (LISN) are an essential component in EMC RF testing. Teseq offers a wide range of CDNs and LISNs used in different applications according to various international standards.

    Keep Reading
  • RF Probes and Clamps

    Absorbing Clamps are used for measuring interference signals on power supply cables. Decoupling clamps and ferrite tube are available for a variety of different EMC applications. The current sensing probes are used for current monitoring applications, such as those required by the BCI standards.

    Keep Reading
  • RF System Components and Accessories

    AMETEK CTS offers specially designed system components for EMC testing requirements featuring a large dynamic range, fast measurement devices, rugged design and a frequency range that matches the application. The system components can be purchased as individual parts or as a full configured system defined by the user for frequency and power requirements.

    Keep Reading
  • GTEM / TEM Cells / Striplines / Reverberation Chambers

    GTEM, DTEM, Striplines and Reverberation Chambers (RCs) are modern EMC test environments in addition to the established methods like semi- or full anechoic rooms and open area test sites. They can be used for emission and immunity testing as required by the IEC / EN 61000-4-20, 21 and other standards.

    Keep Reading
  • Antennas

    AMETEK CTS has an extensive offering of high performance EMC antennas inlcuding the Horn antenas for applications up to 18 GHz, and Loop antennas as required by the medical standard.

    Keep Reading
