CDN AF2 to AF4 From 150 kHz Series

  • Coupling networks designed for IEC/EN 61000-4-6
  • Used for unscreened, unbalanced control lines
  • Models with 4 mm safety banana sockets
  • Models with frequency range 150 kHz to 230 MHz
  • Models with better isolation to ground

  • Overview +


    IEC / EN 61000-4-6 specifies the design and performance of a range of coupling /de-coupling networks (CDNs). Each CDN is specific to the type of cable and the intended signal carried on the cable. AMETEK CTS with its brand TESEQ offers an extensive range of CDNs which fully comply with the requirements of the standard and provide a simple and reliable method of injecting RF energy into the equipment under test (EUT). In this datasheet, CDN used with unscreened unbalanced for data communications with different line application starting from 150 kHz as required by IEC / EN 61000-4-6 is presented. The presented CDN AF series is used to Inject common mode disturbance signal into unscreened and unbalanced control lines with low currents and a maximum of four lines in the frequency range from 150 kHz to 230 MHz.
