The CDN 3063A-C100.1 is the first 3-phase Teseq coupling network with a switchable current range. This advancement means that users can now seamlessly cover the entire current spectrum with a single CDN unit. By eliminating the need for multiple CDNs (one for each current range), the CDN 3063A-C100.1 not only delivers cost savings but also streamlines the testing setup process for users.
Designed to meet the requirements of the current surge standard IEC 61000-4-5 Ed. 3, the CDN 3063A-C100.1 offers selectable current ranges of 32 A, 63 A, and 100 A. The CDN 3063A-C100.1 also dynamically adjusts its decoupling inductance based on the chosen current range. The new product is packaged in a 34 HU rack that can also accommodate the NSG 3060A compact generator.
Key Features of the CDN 3063A-C100.1:
