AR is committed to provide the finest antenna and equipment under test accessories to meet your requirements.
Mounting your antenna to a tripod allows for easy rotation of the antenna to the desired position. All our antennas are designed to mount easily on a tripod or to a mounting plate. The microwave horn tripod mounting systems include a swivel head, antenna bracket, and mounting cylinder. The tripod is constructed of durable, non-conductive, commercial grade fiberglass and plastic that provide the necessary stability while allowing for portability.
Antenna mounting adapters are also available for older versions of the AT1000, AT1080, and AT5080 antennas. Positioners are available (in the model positioner for models ATR26M6G, ATR26M6G-1, ATR26M1G and ATR26M250) for the larger horn antennas. All these devices allow for vertical and horizontal polarization changes without removing the antenna from the tripod/positioner.
|
Tripods, Stands & Positioners
|
 |
|
Model
|
Description
|
|
AM1000
|
Antenna Mounting Adapter – allows horizontal and vertical polarization change without removing antenna from tripod (For AT1000, AT1000A)
|
|
AM1001
|
Antenna Mounting Adapter – allows horizontal and vertical polarization change without removing antenna from tripod (For AT1080, AT1080A)
|
|
AM6000
|
Antenna Mounting Adapter – allows horizontal and vertical polarization change without removing antenna from tripod (For AT5080, AT6080)
|
|
AM7000A
|
Antenna Mounting Adapter – allows horizontal and vertical polarization change without removing the antenna from a tripod (For ATH6G18A)
|
|
AM8000
|
Antenna Mounting Adapter – allows horizontal and vertical polarization change without removing antenna from tripod (For AT4002A, AT4510, ATH1G4, ATH800M5G, ATH800M5GA, ATH800M6G)
|
|
AM9000
|
Antenna Mounting Adapter – allows horizontal and vertical polarization change without removing the antenna from the tripod (Use this adaptor to mount antennas that use 1/4-20 hardware to the TP1000B tripod)
|
|
AP5010B
|
Positioner for models ATR26M6G, ATR26M6G-1, ATR26M1G and ATR26M250
|
|
TM1000
|
Microwave horn tripod mounting system (includes swivel head, antenna bracket and mounting cylinder) for WRD-750 D24 waveguide and ATH7G18 antenna.
|
|
TM1001
|
Tripod mounting system for WR-42 waveguide and ATH18G27 and ATH18G27-1 antennas
|
|
TM1002
|
Tripod mounting system for WR-28 waveguide and ATH26G40 and ATH26G40-1 antennas
|
|
TP1000B
|
Non-Metallic Tripod. Will support most AR antennas weighing less than 27.2 kg (60 lbs). See specification sheet for full list of applicable antennas.
|
|
TP1000BM1
|
Same as TP1000B plus casters/leveling feet & swivel adapter
|
|
TP2000
|
Standard Metallic Tripod. Will support most AR antennas weighing less than 7.96 kg (17.6 lbs). See specification sheet for full list of applicable antennas.
|
|
TP2010
|
Metallic Heavy-Duty Tripod
|
|
TP3000
|
High-quality wooden-legged tripod. Ideal for use with the SM40G and SM400K Safety Meters
|
|
TP4000
|
Metallic Tripod for models ATH200M1G and ATH200M1G-1
|
|
TPK1000
|
Non-metallic Tripod Accessory Kit (for models TP1000A and TP1000B)
|
