An E-field generator is a type of antenna which generates high intensity electric fields from RF Power. E-field generators are used to create the required field strength over a wide range of frequencies in an anechoic chamber or open area test site (OATS). Use the parametric search tools to narrow down on products by Frequency, Electric Field Intensity, and various other parameters.
AR E-field generators offer exceptional uniformity between the elements. Our ATE10K30M uses low inductance high-power internal load resistors to terminate RF power and offers well-matched input VSWR. The ATE10K100M is our own patent-pending folded-dipole type design. And we haven’t yet found a test object the ATE10K25M–1 can’t handle.
The AR RF/Microwave Instrumentation is a E-Field Generator with Frequency 10 kHz to 100 MHz, and Input Power up to 3000 W.
|
E Field Generators
|
 10kHz - 100MHz |
|
Model
|
Description
|
|
ATE10K25M-1
|
10 kHz – 25 MHz, 3000 W input power, E Field Generator
|
|
ATE10K30MA
|
10 kHz – 30 MHz, 2000 W input power, E Field Generator
|
|
ATE10K100M
|
10 kHz – 100 MHz, 500 W input power, E Field Generator
|
|
ATP10K100M
|
10 kHz – 100 MHz, 3000 W input power, Broadband Transmission Line, supplied with basic stand
|
