The “U” Series customizable, Class A design is ideal for laboratory and EMC testing, as well as testing antennas, components, piezoelectric devices, wireless chargers, and more. The “U” Series offers performance and durability with the power and frequency for universal applications.
With a single band amplifier, each "U" Universal Series instrument can instantly cover a frequency range of 10 kHz to 1000 MHz. This makes them perfect for a variety of testing, including EMC testing, laboratory testing, antenna and component testing, watt meter calibration, and medical/physics research. There is no limit to the applications for these adaptable amplifiers because custom versions are also offered.
For laboratory and EMC testing, as well as testing antennas, components, piezoelectric devices, wireless chargers, and more, the Class A, configurable "U" Series design is perfect.
Performance and robustness along with power and frequency for a wide range of applications are provided by the "U" Series. Apart from the variants mentioned below, personalized versions.
When powered by a sweep generator, the first models—10U1000, 25U1000, 50U1000, 100U1000A, 150U1000, and 250U1000A—offer a minimum of 10, 25, 50, 100, 150, and 250 watts CW of RF power.
These cutting-edge amplifiers also span the widest frequency range of any amplifier of comparable power—while remaining compact and delivering performance, longevity, and durability.
|
“U” Series Amplifiers
|
 10kHz - 1000 MHz
|
|
Model
|
Description
|
|
10U1000
|
10 W CW, 10 kHz – 1000 MHz
|
|
25U1000
|
25 W CW, 10 kHz – 1000 MHz
|
|
100U1000A
|
00 W CW, 10 kHz – 1000 MHz
|
|
50U1000
|
50 W CW, 10 kHz – 1000 MHz
|
|
150U1000
|
150 W CW, 10 kHz – 1000 MHz
|
|
250U1000A
|
250 W CW, 10 kHz – 1000 MHz
|
