Microwave Amplifiers

AR’s microwave amplifiers are just as tough and dependable as our RF amplifiers, and they are backed by the same comprehensive warranty. These amplifiers offer the hard-to-find combinations of power and bandwidth in frequency increments and power output you need for today’s test applications. These devices are essential for enhancing the strength of microwave signals, enabling long-distance transmission and reliable communication across various applications, including satellite communication, radar systems, and wireless networks.

At their core, microwave amplifiers utilize active devices such as vacuum tubes or transistors to amplify microwave signals while maintaining their integrity. One of the key challenges in designing microwave amplifiers is achieving high gain and low noise figure while operating at microwave frequencies, typically ranging from 1 GHz to 100 GHz.

These microwave amplifiers have been designed have serious considerations on gain, noise figure, stability, linearity, and power efficiency. Our team of expert engineers utilize advanced simulation tools and optimization techniques to meet the stringent requirements of modern communication systems.

Microwave amplifiers are indispensable components in microwave communication systems, providing the necessary signal amplification for reliable and efficient transmission across various applications. Whether in satellite communication, radar systems, or wireless networks, the continuous advancement of microwave amplifier technologies contributes to the evolution of communication infrastructure, enabling seamless connectivity and information exchange on a global scale.

Microwave Amplifiers
1.0 GHz to 2.8 GHz
125S1G2z5	125 W CW, 1 – 2.5 GHz
250S1G2z5B	250 W CW, 1 – 2.5 GHz
500S1G2z5A	500 W CW, 1 – 2.5 GHz
1000S1G2z5B	1000 W CW, 1 – 2.5 GHz
2000S1G2z8	2000 W CW, 1.0 – 2.8 GHz
0.8 GHz to 4.0 GHz
AR08M4-030	30 W CW, 0.8 – 4.0 GHz
AR08M4-060	60 W CW, 0.8 – 4.0 GHz
AR08M4-100	100 W CW, 0.8 – 4.0 GHz
AR08M4-200	200 W CW, 0.8 – 4.0 GHz
AR08M4-400	400 W CW, 0.8 – 4.0 GHz
AR08M4-800	800 W CW, 0.8 – 4.0 GHz
0.8 GHz to 6.0 GHz
AR08G6-030	30 W CW, 0.8 – 6.0 GHz
AR08G6-060	50 W CW, 0.8 – 6.0 GHz
AR08G6-120	100 W CW, 0.8 – 6.0 GHz
AR08G6-200	200 W CW, 0.8 – 6.0 GHz
AR08G6-400	400 W CW, 0.8 – 6.0 GHz
1.0 GHz to 6.0 GHz
30S1G6C	30 W CW, 1 – 6 GHz
75S1G6C	75 W CW, 1 – 6 GHz
125S1G6C	125 W CW, 1.0 – 6.0 GHz
250S1G6C	250 W CW, 1 – 6 GHz
500S1G6C	500 W CW, 1.0 – 6.0 GHz
750S1G6C	750 W (1.0 to 4.2 GHz), 500 W (4.2 to 6.0 GHz)
1000S1G6C	1000 Watts (1.0 to 5.0 GHz), 700 Watts (5.0 to 6.0 GHz)
4.0 GHz to 8.0 GHz
AR4i8-030	30 W CW, 4.0 – 8.0 GHz
AR4i8-050	50 W CW, 4.0 – 8.0 GHz
AR4i8-100	100 W CW, 4.0 – 8.0 GHz
AR4i8-200	200 W CW, 4.0 – 8.0 GHz
AR4i8-400	400 W CW, 4.0 – 8.0 GHz
6.0 GHz to 18.0 GHz
20S6G18C	20 W CW, 6 – 18 GHz, Air Cooled
40S6G18C	40 W CW, 6 – 18 GHz, Air Cooled
75S6G18C	75 W CW, 6 – 18 GHz, Air Cooled
125S6G18C	125 W CW, 6 – 18 GHz, Air Cooled
250S6G18C	250 W CW, 6 – 18 GHz, Air Cooled
450S6G18C	450 W CW, 6 – 18 GHz, Air Cooled
