RF Amplifiers

Our “A” and “W” Series amplifiers have the power to deliver all the field strength you need. With unsurpassed mismatch capabilities and excellent flatness, they provide all the power promised over the entire operating band.

Below are the Product Datasheets of RF Amplifiers:

  • 4 kHz to 400 MHz
  • 10 kHz to 100 MHz
  • 10 kHz to 225 MHz
  • 10 kHz to 250 MHz
  • 10 kHz to 400 MHz
  • 80 MHz to 1000 MHz
    We rigorously test our amplifiers under extreme conditions to ensure lasting reliability and top performance. From enduring harsh environments to handling varying output VSWR loads, our amplifiers are built to excel. The only problem we ran into was that there were no available loads to handle the enormous power up to 80,000 W that our amplifiers deliver. Whereas this would stop most manufacturers, it presented another challenge to our talented designers, and we designed our own. All our RF solid-state amplifiers have modulation capability that will faithfully reproduce AM, FM or Pulse Modulation appearing on the input signal for use in the most demanding EMC applications.

    These technologically advanced amplifiers perform beyond the norm, beyond expectations, and way beyond the abilities of other test amplifiers.

    These self-contained, broadband, completely solid-state amplifiers are designed for applications requiring the ultimate in output power over a wide instantaneous bandwidth with high gain. Extensive control and status reporting capabilities are available both locally and remotely. Most models feature air-cooled designs while some higher power units feature liquid cooled designs. The touch-screen panels are intuitive, convenient, and easy to use.

    High Power RF Amplifiers

    RF Amplifiers

    10 kHz to 250 MHz
    100A400AM20 100 W CW, 4 kHz – 400 MHz – For BCI testing

    10 kHz to 100 MHz
    150A100D 150 W CW, 10 kHz – 100 MHz

    10 kHz to 225 MHz
    1200A225D 1200 W CW, 10 kHz – 225 MHz
    2500A225D 2500 W CW, 10 kHz – 225 MHz
    5000A225D 5000 W CW, 10 kHz – 225 MHz
    10000A225D 10000 W CW, 10 kHz – 225 MHz, Air Cooled

    10 kHz to 250 MHz
    25A250B 25 W CW, 10 kHz – 250 MHz
    50A250 50 W CW, 10 kHz – 250 MHz
    125A250 125 W CW, 10 kHz – 250 MHz
    500A250D 500 W CW, 10 kHz – 250 MHz

    10 kHz to 400 MHz
    100A400A 100 W CW, 10 kHz – 400 MHz
    175A400 175 W CW, 10 kHz – 400 MHz
    250A400 250 W CW, 10 kHz – 400 MHz
    350A400 350 W CW, 10 kHz – 400 MHz
    600A400 600 W CW, 10 kHz – 400 MHz
    1000A400 1000 W CW, 10 kHz – 400 MHz

    80 MHz to 1000 MHz
    50W1000D 50 W CW, 50-1000 MHz
    125W1000A 125 W CW, 80 – 1000 MHz
    150W1000B 150 W CW, 80 – 1000 MHz
    250W1000C 250 W CW, 80 – 1000 MHz
    500W1000C 500 W CW, 80 – 1000 MHz
    1000W1000J 1000 W CW, 80 – 1000 MHz
    2000W1000F 2000 W CW, 80 – 1000 MHz
    3000W1000B 3000 W CW, 80 – 1000 MHz
    4000W1000B 4000 W CW, 80 – 1000 MHz
    6000W1000 6000 W CW, 80 – 1000 MHz
    10000W1000A 10000 W CW, 80 – 1000 MHz
